Switched sockets in thermosetting (GRP) with mechanical interlock and fuse-holder (M95), for wall mounting IP66/IP67/IP69

Data sheet Rated current Frequency Rated operating voltage Poles Clock Position Code
16A 50/60Hz 110V 2P+ 4h 472610
16A 50/60Hz 110V 3P+ 4h 472710
16A 50/60Hz 110V 3P+N+ 4h 472810
16A 50/60Hz 230V 2P+ 6h 472620
16A 50/60Hz 230V 3P+ 9h 472720
16A 50/60Hz 230V 3P+N+ 9h 472820
16A 50/60Hz 400V 2P+ 9h 472630
16A 50/60Hz 400V 3P+ 6h 472730
16A 50/60Hz 400V 3P+N+ 6h 472830
16A 50/60Hz 500V 3P+ 7h 472750
16A 50/60Hz 500V 3P+N+ 7h 472840
16A 50/60Hz >50V for isolation transformer 2P+ 12h 472640
16A 50/60Hz >50V for isolation transformer 3P+ 12h 472760
16A 100-300Hz >50V 2P+ 10h 472650
16A 100-300Hz >50V 3P+ 10h 472780
16A 100-300Hz >50V 3P+N+ 10h 472870
16A >300-500Hz >50V 2P+ 2h 472660
16A >300-500Hz >50V 3P+ 2h 472790
16A >300-500Hz >50V 3P+N+ 2h 472880
16A 60Hz 440-460V 3P+ 11h 472740
16A 60Hz 440-460V 3P+N+ 11h 472850
16A DC >50-250V 2P+ 3h 472670
32A 50/60Hz 110V 2P+ 4h 468224
32A 50/60Hz 110V 3P+ 4h 468234
32A 50/60Hz 230V 2P+ 6h 468226
32A 50/60Hz 230V 3P+ 9h 468239
32A 50/60Hz 400V 2P+ 9h 468229
32A 50/60Hz 400V 3P+ 6h 468236
32A 50/60Hz 380/440V 3P+ 3h 468233
